One of the high strength rivets is the Monobolt and Interlock type rivets, which have the advantage of a large grip range and hole filling, which results in exceptionally high shear and tension strength values. Provides a strong vibration-resistant joint, which also reduces the risk of water infiltration (not waterproof). Due to the special pulling rod design during riveting, the mandrel is permanently fixed. Monobolt rivets require a special riveting nose piece, while Interlock rivets do not require this.

One of the high strength rivets is the Hemlok type rivet, which has the advantage of large and strong washer like forming at back side during riveting.

It has exceptionally high shear and tear strength values. Provides strong vibration resistant fixing. During riveting, the mandrel is permanently fixed due to the special locking mechanism.

No special riveting head is needed, just a powerful riveting machine like POPAvdel XT4.

Hole filling rivets have a special design that has a significant advantage over conventional rivets.

It has the advantage of bigger bulb forming behind the plate during riveting, which increases the tensile strength.
The rivet shank is attached to the rivet body so that it cannot fall out from the rivet body (recommended for electrical boxes)
The accuracy of the hole is less important as the rivet widens laterally, increasing shear strength and tensile strength

With the help of a rivet nut, it is easy to insert a thread into either a thin or soft material, and the strength of thread is high. This saves time on tapping or welding a nut. One-sided installation with a simple operation. The material does not deform or discolour during operation. In addition to its basic function, it can be used to fix together multiple sheets, just like pop rivets. Available in Flat, Countersunk, Small countersunk and Micro-flanged head designs, in Cylindrical, Hexagonal, Rectangular, Open and Closed versions in aluminum, steel and stainless steel (A2 or A4)or even Titanium.

Speed riveting process: Pull the cartridge paper (rivet inside) onto the mandrel, support it with a spring, and remove the paper from the rivet. Insert it into the machine. By actuating the trigger, the conical end of the mandrel extends the speed rivet's body, thus fixing the rivet. The next speed rivet is fed automatically. This series riveting method achieves a maximum of 1500 rivets per hour that lowers the labour cost.

‹ ›

POP AVDEL 07420-12000

Hydro pneumatic rivet nut tool is a state of the art machine. Strong, reliable, light weight, stroke adjused machine which is capeable to set M3-M12 rivet nuts without problem. One-step trigger reduces cycle time to minimum.

POP AVDEL® XT1 HYDRO PNEUMATIC TOOL

Placing capability:
Up to 4.8 mm (3/16") aluminium breakstem rivets and up to 4.0 mm (5/32") steel breakstem rivets produced by Avdel. Can also place Avseal® II 4 and 5 mm sealing plugs.
For detailed information on placing capability and nose equipment please click here

‹›

Fasteners, rivets, rivet nuts, riveting tools

What is a cordless battery riveting tool? You can find out today!

Created: Friday, 05 August 2022 20:50

Today we discuss in detail what a cordless battery rivet tool is. What’s more, you’ll also learn about the pros and cons of this machine, so we encourage you to read on!

There are about 600,000 traditional (flanged) rivets in each tower of the Golden Gate Bridge in San Francisco. This number is the result of an incredibly persistent and exceptional work that was done even when the cordless rivet tool did not exist. But what luck that technology is evolving and has been helping our lives ever since! In many cases the traditional rivets been replaced by pop rivets (in other name blind rivets).

Do not happen to you what happened to Titanic

Created: Friday, 05 August 2022 07:24

Although rivets are small, they are strong and their quality is very important. Choosing the right type and good quality rivet, can provide secure permanent fastening and fixing; they can also make DIY at home easier for you. However, catching poor quality pop rivets can be a number of annoyances or even costly for many manufacturers, from electronics to the mechanical engineering industry to fine mechanics.

Poorer quality rivets resulted in the sinking of one of the largest ships of the 20th century, the Titanic. So it is worth choosing carefully!
